Engineered product rejection

Reject conveyor systems that remove every failed pack.

Positive rejection, independent verification and fail-safe monitoring—engineered around your product, inspection equipment and production line.

Request an application review →Explore reject methods ↓
  • ✓ UK-wide integration
  • ✓ Food & pharmaceutical options
  • ✓ New or existing lines

Integrated with

VISION INSPECTIONCHECKWEIGHINGMETAL DETECTIONX-RAYBARCODE VERIFICATION

The right action for every pack

A reject conveyor is only effective when the failed product is positively removed.

Oxford Vision Systems designs reject handling as part of the inspection process—not as an afterthought. We consider product behaviour, conveyor speed, rejection distance, accumulation, guarding, access and the response to a fault.

The result is a practical system that protects good production, contains rejects securely and gives operators clear evidence that the correct pack was removed.

Tell us about your application →

Reject mechanisms

Select the reject method around the product—not the other way round.

From lightweight sachets to heavy cases, each mechanism is sized and timed for dependable separation at production speed.

01↗

Pneumatic pusher reject conveyors

Fast, controlled and dependable rejection for rigid packs on automated production lines.

EXPLORE SYSTEM
02↗

Air-blast reject systems

Rapid removal of lightweight products without a mechanical arm entering the product flow.

EXPLORE SYSTEM
03↗

Drop-flap reject systems

A secure reject path for small packs and applications where positive downward removal is preferred.

EXPLORE SYSTEM
04↗

Retracting-belt reject systems

Controlled rejection for products that cannot be pushed, blown or dropped aggressively.

EXPLORE SYSTEM
05↗

Swing-arm diverters

Positive routing of larger packs and cases into reject, rework or alternate production lanes.

EXPLORE SYSTEM
06↗

Lane-divert systems

Track, separate and route products between conveyor lanes with controlled automation.

EXPLORE SYSTEM
Not sure which mechanism fits?

Send us a product sample, pack dimensions, weight, line speed and a short production video. We will identify the most suitable reject principle.

Start a technical review
FOOD-GRADE BUILD
100%positive reject path

Closed-loop rejection

Know that the failed product has left the line.

An output signal alone does not prove successful rejection. A verified system tracks the suspect pack through every critical stage.

  1. 01

    Reject signal received and product tracked

  2. 02

    Reject device actuated within the validated window

  3. 03

    Independent sensor confirms product entered the bin

  4. 04

    Full-bin and bin-present status continuously monitored

  5. 05

    Line stop or alarm raised if rejection is not confirmed

!

Fail-safe response Alarm, controlled line stop or production lockout can be configured around your risk assessment and user-requirement specification.

LOCK

Lockable reject bins

Secure failed product from unauthorised removal or reintroduction.

BIN

Bin-present sensing

Prevent production when the reject container is missing or incorrectly fitted.

FULL

Full-bin detection

Warn operators before capacity is exceeded and the reject route is compromised.

VERIFY

Independent confirmation

Confirm each failed product has entered the controlled reject area.

Built around your environment

Reject stations for demanding production sectors.

01 / PHARMACEUTICAL

Controlled reject handling for high-integrity lines

Compact reject stations for cartons, bottles, blister packs and medical products, with secure containment, access monitoring, reject verification and clear fault states.

  • Lockable or tamper-resistant bins
  • Bin-present and door-open monitoring
  • PLC and inspection-system integration
  • Validation-support documentation options
Pharmaceutical systems →
02 / FOOD & BEVERAGE

Hygienic, cleanable conveyor construction

Stainless-steel frames and food-compatible components configured around product contact, washdown and cleaning requirements.

03 / GENERAL MANUFACTURING

Robust rejection for packs, components and cases

Flexible integration with inspection, counting, dimensional checking, print verification and line-control systems.

Inspection and application guides

Find the reject system for your inspection equipment and product.

Use these focused guides to compare integration, containment, verification and project requirements before requesting an engineered quotation.

WEIGHT CONTROL

Checkweigher reject conveyors

Remove underweight and overweight packs with tracked, verified rejection.

View application →CONTAMINANT CONTROL

Metal detector reject systems

Positive removal, secure bins and fail-safe monitoring after metal detection.

View application →X-RAY INSPECTION

X-ray inspection reject systems

Route contamination, integrity and missing-item failures to controlled destinations.

View application →MACHINE VISION

Vision inspection reject systems

Convert camera decisions into accurately tracked physical rejection.

View application →CONTAINER LINES

Bottle, can and jar rejects

Stable, controlled removal for upright containers and close-running products.

View application →EXISTING LINES

Reject conveyor retrofit

Add automatic rejection to suitable conveyors and inspection equipment.

View retrofit guide →PROJECT BUDGET

Reject conveyor cost guide

Understand the factors that shape a complete engineered quotation.

View cost guide →BUYER'S GUIDE

How to choose a reject system

Compare air blast, pusher, flap, retracting belt and divert methods.

Compare methods →

New engineering guides

Engineering guidance for demanding reject applications.

Plan high-speed handling, additional reject methods, difficult product formats, PLC tracking, acceptance tests and food-line fail-safe controls.

ENGINEERING GUIDE

High-speed reject conveyor systems

High-speed reject conveyor systems engineered around pack pitch, belt speed, tracking, actuator recovery and verified product removal.

Read guide →ENGINEERING GUIDE

Stop-on-detect reject systems

Stop-on-detect conveyor systems for heavy, awkward or low-rate products, with alarms, controlled removal and monitored restart conditions.

Read guide →ENGINEERING GUIDE

Overhead sweep reject systems

Overhead sweep reject conveyor systems for stable packs, cartons and cases where a top-mounted sweeping action suits the line layout.

Read guide →ENGINEERING GUIDE

Sachet and pouch reject conveyors

Reject conveyor systems for sachets, pouches and flexible packs, with stable handling, accurate tracking and verified removal.

Read guide →ENGINEERING GUIDE

Carton and case reject conveyors

Automatic carton, box and case reject conveyors using pushers, sweep arms or diverters with tracking and transfer confirmation.

Read guide →ENGINEERING GUIDE

Reject conveyor product tracking and timing

How reject conveyor product tracking links an inspection failure to the correct pack using sensors, encoders, PLC timing and verification.

Read guide →ENGINEERING GUIDE

Reject conveyor testing and validation

Plan reject conveyor FAT and SAT testing, including product trials, challenge rejects, sensor faults, bin monitoring and acceptance evidence.

Read guide →ENGINEERING GUIDE

Food safety fail-safe reject systems

Plan fail-safe food-line reject systems with reject confirmation, lockable bins, low-air, bin-full and access monitoring.

Read guide →
Need the complete guide index?

Use the engineering guide hub to compare every topic and move between related reject mechanisms.

View all engineering guides

From product to production

A clear engineering path to dependable rejection.

01

Application review

Define the product range, speed, inspection interface, environment and failure response.

02

Concept & specification

Select the mechanism, conveyor geometry, guarding, sensors and reject containment.

03

Build & product testing

Assemble and test against agreed products and operating scenarios before dispatch.

04

Integration & support

Installation, commissioning, training and ongoing technical support across the UK.

Frequently asked questions

Practical answers before you specify a reject conveyor.

Have a different question? Speak directly with an engineer about your product and inspection line.

Call 01865 416657 →
Which reject mechanism is best for my product?+

The correct mechanism depends on pack weight, stability, line speed, conveyor width, space and the reason for rejection. We review the complete application before recommending a pusher, air blast, drop flap, retracting belt or diverter.

Can a reject conveyor connect to an existing inspection system?+

Yes. Systems can interface with vision inspection, checkweighing, metal detection, X-ray, barcode verification and other line controls.

What does reject verification do?+

An independent sensor confirms that the identified failed product physically left the accepted-product flow. A missing confirmation can raise an alarm or stop the line.

Are food-grade stainless-steel conveyors available?+

Yes. Stainless-steel frames, hygienic materials and cleanable designs can be specified around the product, environment and cleaning regime.

Can pharmaceutical reject stations use lockable bins?+

Yes. Lockable or tamper-resistant bins can be combined with bin-present, access-open and full-bin monitoring.

Start your application review

Tell us what must be rejected—and what happens if it is not.

Share your product, pack size, line speed and current inspection equipment. An Oxford Vision Systems engineer will review the application and contact you.

Call our team01865 416657Email an enquirysales@oxfordvisionsystems.co.uk

No mailing lists. Your details are used only to handle this enquiry.

How does a conveyor reject system remove the correct product?

Define how the failed product is identified and tracked from the inspection point to removal. Include pack spacing, conveyor speed changes and the reject destination. Challenge the sequence with consecutive failures, missing products and a full reject container, then agree confirmation, alarms and recovery before accepting the system.

Related guidance: Explore metal-detector reject conveyors.

Also see: Explore pneumatic pusher reject conveyors.

Also see: Explore reject conveyor selection guide.

What should a reject-conveyor design do after a pack is diverted?

Define where rejected packs go, how they are kept separate and how the production team reviews them. Include pack weight, stability and the expected reject rate. Agree the response to a full collection area or failed transfer so rejected product cannot silently return to the accepted-product flow.

Related guidance: Explore reject conveyor selection guide · Existing-line retrofits
